Dane techniczne
Elektrozawory 2/2 Parker Lucifer bezpośredniego działania do stref ATEX:
- normalnie zamknięte NC
- przyłącze: G1/4"
- dedykowane do wszystkich cieczy i powietrza
- uszczelnienie: FKM, Rubin lub PCTFE
- max temperatura pracy: 80°C
- materiał: mosiądz
Jak zamawiać
Skontaktuj się z inżynierem sprzedaży, szczegóły dostępne w zakładce
Kontakt z inżynieremKontakt z inżynierem sprzedaży
Produkty dostępne w sklepie internetowym
| Lp. | Kod produktu | Przył. | ATEX | Ø mm | Uszcz. | Kv l/min | KV m3/h | Qn l/min | C min bar | C max bar | T min °C | T max °C | Moc W | Napięcie | Dostępność | Koszyk |
| 1 | E121K65-2995-4958703D | 1/4" | 2-22 | 1,2 | Rubin | 0,85 | 0,05 | 50 | 0 | 80 | 0 | 50 | 8 | 220-230V/50Hz |  | |
| 2 | E121K65-2995-495870C2 | 1/4" | 2-22 | 1,2 | Rubin | 0,85 | 0,05 | 50 | 0 | 36 | 0 | 50 | 9 | 24VDC | | |
| 3 | E121K65-495905F4 | 1/4" | 1-21 | 1,2 | Rubin | 0,85 | 0,05 | 50 | 0 | 80 | 0 | 80 | 8 | 230V/50Hz | | |
| 4 | E121K65-495905C2 | 1/4" | 1-21 | 1,2 | Rubin | 0,85 | 0,05 | 50 | 0 | 36 | 0 | 80 | 8 | 24VDC | | |
| 5 | E121K04-2995-4958703D | 1/4" | 2-22 | 1,5 | PCTFE | 1,5 | 0,09 | 80 | 0 | 70 | 0 | 50 | 8 | 220-230V/50Hz | | |
| 6 | E121K04-2995-495870C2 | 1/4" | 2-22 | 1,5 | PCTFE | 1,5 | 0,09 | 80 | 0 | 30 | 0 | 50 | 9 | 24VDC | | |
| 7 | E121K04-495905F4 | 1/4" | 1-21 | 1,5 | PCTFE | 1,5 | 0,09 | 80 | 0 | 60 | 0 | 80 | 8 | 230V/50Hz | | |
| 8 | E121K04-495905C2 | 1/4" | 1-21 | 1,5 | PCTFE | 1,5 | 0,09 | 80 | 0 | 25 | 0 | 80 | 8 | 24VDC | | |
| 9 | 121K0706-2995-4958703D | 1/4" | 2-22 | 2,5 | FKM | 3,5 | 0,21 | 220 | 0 | 14 | 0 | 50 | 8 | 220-230V/50Hz | | |
| 10 | 121K0706-2995-495870C2 | 1/4" | 2-22 | 2,5 | FKM | 3,5 | 0,21 | 220 | 0 | 7 | 0 | 50 | 9 | 24VDC | | |
| 11 | 121K0706-495905F4 | 1/4" | 1-21 | 2,5 | FKM | 3,5 | 0,21 | 220 | 0 | 14 | 0 | 80 | 8 | 220-230V/50Hz | | |
| 12 | 121K0706-495905C2 | 1/4" | 1-21 | 2,5 | FKM | 3,5 | 0,21 | 220 | 0 | 7 | 0 | 80 | 8 | 24VDC | | |
| 13 | E121K63-2995-4958703D | 1/4" | 2-22 | 2,5 | Rubin | 3,5 | 0,21 | 220 | 0 | 28 | 0 | 50 | 8 | 220-230V/50Hz | | |
| 14 | E121K63-2995-495870C2 | 1/4" | 2-22 | 2,5 | Rubin | 3,5 | 0,21 | 220 | 0 | 10 | 0 | 50 | 9 | 24VDC | | |
| 15 | E121K63-495905F4 | 1/4" | 1-21 | 2,5 | Rubin | 3,5 | 0,21 | 220 | 0 | 28 | 0 | 80 | 8 | 230V/50Hz | | |
| 16 | E121K63-495905C2 | 1/4" | 1-21 | 2,5 | Rubin | 3,5 | 0,21 | 220 | 0 | 10 | 0 | 80 | 8 | 24VDC | | |
| 17 | E121K03-2995-4958703D | 1/4" | 2-22 | 3 | PCTFE | 4,5 | 0,27 | 320 | 0 | 20 | 0 | 50 | 8 | 220-230V/50Hz | | |
| 18 | E121K03-2995-495870C2 | 1/4" | 2-22 | 3 | PCTFE | 4,5 | 0,27 | 320 | 0 | 7 | 0 | 50 | 9 | 24VDC | | |
| 19 | E121K03-495905F4 | 1/4" | 1-21 | 3 | PCTFE | 4,5 | 0,27 | 320 | 0 | 20 | 0 | 80 | 8 | 230V/50Hz | | |
| 20 | E121K03-495905C2 | 1/4" | 1-21 | 3 | PCTFE | 4,5 | 0,27 | 320 | 0 | 7 | 0 | 80 | 8 | 24VDC | | |
| 21 | E121K0302-2995-4958703D | 1/4" | 2-22 | 3 | FKM | 4,5 | 0,27 | 320 | 0 | 10 | 0 | 50 | 8 | 220-230V/50Hz | | |
| 22 | E121K0302-2995-495870C2 | 1/4" | 2-22 | 3 | FKM | 4,5 | 0,27 | 320 | 0 | 7 | 0 | 50 | 9 | 24VDC | | |
| 23 | E121K0302-495905F4 | 1/4" | 1-21 | 3 | FKM | 4,5 | 0,27 | 320 | 0 | 10 | 0 | 80 | 8 | 230V/50Hz | | |
| 24 | E121K0302-495905C2 | 1/4" | 1-21 | 3 | FKM | 4,5 | 0,27 | 320 | 0 | 7 | 0 | 80 | 8 | 24VDC | | |
| 25 | E121K64-5995-4958703D | 1/4" | 2-22 | 3 | Rubin | 4,5 | 0,27 | 320 | 0 | 20 | 0 | 50 | 8 | 220-230V/50Hz | | |
| 26 | E121K64-2995-495870C2 | 1/4" | 2-22 | 3 | Rubin | 4,5 | 0,27 | 320 | 0 | 7 | 0 | 50 | 9 | 24VDC | | |
| 27 | E121K64-495905F4 | 1/4" | 1-21 | 3 | Rubin | 4,5 | 0,27 | 320 | 0 | 20 | 0 | 80 | 8 | 230V/50Hz | | |
| 28 | E121K64-495905C2 | 1/4" | 1-21 | 3 | Rubin | 4,5 | 0,27 | 320 | 0 | 7 | 0 | 80 | 8 | 24VDC | | |
| 29 | 121K02-2995-4958703D | 1/4" | 2-22 | 4 | FKM | 7,5 | 0,45 | 480 | 0 | 10 | 0 | 50 | 8 | 220-230V/50Hz | | |
| 30 | 121K02-2995-495870C2 | 1/4" | 2-22 | 4 | FKM | 7,5 | 0,45 | 480 | 0 | 4 | 0 | 50 | 9 | 24VDC | | |
| 31 | 121K02-495905F4 | 1/4" | 1-21 | 4 | FKM | 7,5 | 0,45 | 480 | 0 | 10 | 0 | 80 | 8 | 230V/50Hz | | |
| 32 | 121K02-495905C2 | 1/4" | 1-21 | 4 | FKM | 7,5 | 0,45 | 480 | 0 | 5 | 0 | 80 | 8 | 24VDC | | |
| 33 | 121K01-2995-4958703D | 1/4" | 2-22 | 5 | FKM | 11 | 0,66 | 750 | 0 | 5 | 0 | 50 | 8 | 220-230V/50Hz | | |
| 34 | 121K01-2995-495870C2 | 1/4" | 2-22 | 5 | FKM | 11 | 0,66 | 750 | 0 | 4 | 0 | 50 | 9 | 24VDC | | |
| 35 | 121K01-495905F4 | 1/4" | 1-21 | 5 | FKM | 11 | 0,66 | 750 | 0 | 7 | 0 | 80 | 8 | 230V/50Hz | | |
| 36 | 121K01-495905C2 | 1/4" | 1-21 | 5 | FKM | 11 | 0,66 | 750 | 0 | 2 | 0 | 80 | 8 | 24VDC | | |
2 drogowy normalnie zamknięty
