Dane techniczne
Elektrozawory 2/2 bezpośredniego działania Mangalift:
- normalnie zamknięte NC High Performance
- przyłącze: 3/8" ÷ 1"
- dedykowane do cieczy i powietrza
- materiał: mosiądz
- uszczelnienie FKM, NBR
- max temperatura pracy: 80°C
Jak zamawiać
Skorzystaj z karty katalogowej lub skontaktuj się z naszym inżynierem sprzedaży (ostatnia zakładka).Kontakt z inżynierem sprzedaży
Produkty dostępne w sklepie internetowym
| Lp. | Kod produktu | Przył. | Strefa ATEX | Ø mm | Uszcz. | Przepływ Kv l/min | KV m3/h | Qn l/min | C min bar | C max bar | T min °C | T max °C | Moc W | Napięcie | Dostępność | Koszyk |
| 1 | 221G13-2995-4958703D | 3/8' | 2-22 | 15 | NBR | 65 | 3,9 | 4500 | 0 | 16 | 0 | 50 | 8 | 220-230V/50Hz |  | |
| 2 | 221G13-495905F4 | 3/8" | 1-21 | 15 | NBR | 65 | 3,9 | 4500 | 0 | 16 | 0 | 80 | 8 | 230V/50Hz | | |
| 3 | 221G15-2995-4958703D | 1/2" | 2-22 | 15 | NBR | 65 | 3,9 | 4500 | 0 | 16 | 0 | 50 | 8 | 220-230V/50Hz | | |
| 4 | 221G15-495905F4 | 1/2" | 1-21 | 15 | NBR | 65 | 3,9 | 4500 | 0 | 16 | 0 | 80 | 8 | 230V/50Hz | | |
| 5 | 221G1530-2995-495870C2 | 1/2" | 2-22 | 15 | NBR | 65 | 3,9 | 4500 | 0 | 10 | 0 | 50 | 9 | 24VDC | | |
| 6 | 221G1530-495905C2 | 1/2" | 1-21 | 15 | NBR | 65 | 3,9 | 4500 | 0 | 10 | 0 | 80 | 8 | 24VDC | | |
| 7 | 221G25-2995-4958703D | 1/2" | 2-22 | 15 | FKM | 65 | 3,9 | 4500 | 0 | 16 | 0 | 50 | 8 | 220-230V/50Hz | | |
| 8 | 221G25-495905F4 | 1/2" | 1-21 | 15 | FKM | 65 | 3,9 | 4500 | 0 | 16 | 0 | 80 | 8 | 230V/50Hz | | |
| 9 | 221G2530-2995-495870C2 | 1/2" | 2-22 | 15 | FKM | 65 | 3,9 | 4500 | 0 | 10 | 0 | 50 | 9 | 24VDC | | |
| 10 | 221G2530-495905C2 | 1/2" | 1-21 | 15 | FKM | 65 | 3,9 | 4500 | 0 | 10 | 0 | 80 | 8 | 24VDC | | |
| 11 | 221G16-2995-4958703D | 3/4" | 2-22 | 15 | NBR | 80 | 4,8 | 6000 | 0 | 16 | 0 | 50 | 8 | 220-230V/50Hz | | |
| 12 | 221G16-495905F4 | 3/4" | 1-21 | 15 | FKM | 80 | 4,8 | 6000 | 0 | 16 | 0 | 80 | 8 | 230V/50Hz | | |
| 13 | 221G26-2995-4958703D | 3/4" | 2-22 | 15 | FKM | 80 | 4,8 | 6000 | 0 | 16 | 0 | 100 | 8 | 220-230V/50Hz | | |
| 14 | 221G26-495905F4 | 3/4" | 1-21 | 15 | FKM | 80 | 4,8 | 6000 | 0 | 16 | 0 | 100 | 8 | 230V/50Hz | | |
| 15 | 221G17-2995-4958703D | 1" | 2-22 | 25 | NBR | 170 | 10,2 | 6000 | 0 | 16 | 0 | 50 | 8 | 220-230V/50Hz | | |
| 16 | 221G17-495905F4 | 1" | 1-21 | 25 | NBR | 170 | 10,2 | 6000 | 0 | 16 | 0 | 80 | 8 | 230V/50Hz | | |
| 17 | 221G21-2995-4958703D | 1" | 2-22 | 25 | NBR | 170 | 10,2 | 14000 | 0 | 16 | 0 | 50 | 8 | 220-230V/50Hz | | |
| 18 | 221G21-495905F4 | 1" | 1-21 | 25 | NBR | 170 | 10,2 | 14000 | 0 | 16 | 0 | 80 | 8 | 230V/50Hz | | |
| 19 | 221G2130-2995-495870C2 | 1" | 2-22 | 25 | NBR | 170 | 10,2 | 14000 | 0 | 10 | 0 | 50 | 9 | 24VDC | | |
| 20 | 221G2130-495905C2 | 1" | 1-21 | 25 | NBR | 170 | 10,2 | 14000 | 0 | 10 | 0 | 80 | 8 | 24VDC | | |
